Wing Setup Documentation




(1) UNZIP WING BAG
(2) SET UP CONTROL BAR
(3) FLIP WING AROUND 180 degrees
(4) OPEN ONE SIDE OF WING ... FULL EXTEND
(5) ATTACH KING POST FITTING TO KING POST
(6) OPEN OTHER SIDE OF WING ... FULL EXTEND
(7) PUT IN ALL WING BATTENS
(8) ATTACH PULLEY SYSTEM IN MIDDLE OF WING. ONE PIN ...THIS PUTS TENSION IN THE WING
(9) LIFT WING UP, RESTING ON THE CONTROL BAR.
...ATTACH THE FRONT LINES TO THE WING.
(10) PREFLIGHT WING INSPECTION  (very important do not slack on this)
(11) BRING WING TO BOAT ALWAYS FACING INTO THE WIND.
...WING GOES UNDER THE BAR.
(12) ATTACH TOP BIG BOLT
(13) ATTACH FRONT BOLT
(14) ATTACH JESUS STRAP
(15) ATTACH SIDE CONTROL LINES
15-20 MIN SET UP TIME
YOU'RE READY TO FLY!
